QX-870 Industrial Raster Laser Scanner
The QX-870 laser scanner combines revolutionary flexible connectivity with high performance decoding capabilities to reliably read 1D barcodes in almost any automation environment. Simple to set up and deploy, it features a programmable sweeping raster to read multiple codes, in varying locations, even if they are damaged or misaligned. With plug and play setup, IP65 industrial sealing, and the most aggressive decode algorithms available, the QX-870 an ideal laser scanner for any industrial application.
- Scans/second: 300 to 1400
- Read range: 25 to 762 mm
- Optional Embedded Ethernet TCP/IP & EtherNet/IP
- IP65 enclosure
- Programmable sweeping raster
- Decodes damaged, poorly printed, or misaligned codes
- Ensures high read rates and throughput
Aggressive decoding capabilities allow reliable reading of barcodes out to 76.2 cm, at up to a 25.4 cm beam width.
In addition to sweep angle and speed controls, the QX-870 features a programmable raster with intelligent auto framing technology. Advanced software will automatically frame the raster height and width of the laser to match the barcode, allowing selective targeting of codes within a single read cycle.
|Type||Industrial Raster Laser Scanner|
|Special function||Sweeping Rastar|
|Code Type||1D codes|
|Bar Code Symbologies Supported||Code 39, Codabar, Code 93, Interleaved 2 of 5, Code 128, PDF417, Micro PDF417, Pharmacode, UPC, GS1 Databar, UCC/EAN-128, AIAG|
|Supply voltage||10 to 28 VDC|
