Innovations in panel building create value for your control panels

Recent evolution of control panel design and manufacturing is benefiting panel builders as well as end users and machine builders, resulting in evolution within production facilities that reduces total cost of ownership.

Creating value for your business

With the goal of making panel manufacturing simpler and more efficient, we have innovated new techniques and technologies for panel design, panel manufacturing processes, and wiring. Our Value Design for Panel concept guides the development of control panel products that reduce time and labor costs, power consumption, and control cabinet size.

Products designed to create competitive advantages

Specifications for Value Design products focus on uniform mounting height and depth, reduced overall volume and side-by-side mounting to make room for more capabilities, and wiring capabilities without tools using front access Push-In Plus wiring terminals to decrease installation time. A panel built around Value

Design Concept products provides competitive advantages for panel builders, machine builders and end users:

Downsizing control panels
Saving space inside the panel to add more capability later
Unified dimensions reduces design work
Reducing dead space improves airflow to dissipate heat
Lower temperatures inside the panel increases product reliability, decreases failure rates, and prolongs product life expectancies
Strong vibration resistance during shipping and operation
Reduced process time from design to assembly to shipment
Certified for CE, UL, and CSA to simplify international export
Unified I/O terminal positions improves speed and accuracy of wiring to shorten delivery times

Combining multiple products that share the Value Design concept increases the value to all stakeholders involved with control panel design and use

Omron's Control Panel Value Design Improve airflow

Reducing dead space improves airflow to dissipate heat

Omron Push In Plus terminal vibration resistance

Retightening is not required for Terminal blocks with push-in plus technology. The pressure of the clamp spring holds the ferrule or wire securely, eliminating issues related to screws loosening due t...

Omron Push In Plus terminal versus spring clamp

Greatly reduce wiring effort with Terminal blocks with push-in plus technology.

Omron Push In Plus terminal using thin wires

Unified wiring methods and specifications help shorten delivery times. It is possible to insert wires with ferrules, solid or stranded wires.

Omron Push In Plus terminal versus auto screw driver

The terminal cable entry of our independently developed terminal blocks with push-in plus technology all face forward for easy wire insertion.

Omron Push In Plus terminal offers a clear view

Front-in and front-release wiring. The terminal cable entry of our independently developed terminal blocks with push-in plus technology all face forward for easy wire insertion.

Omron Push In Plus wire using both hands

The terminal mechanism has been designed to hold the screwdriver, enabling you to have both hands free to insert the wiring into the front-facing cable entry point.

Omron Push In Plus terminal easy wire insertion

Using our Terminal blocks with push-in plus technology is easier than inserting an earphone jack.

Omron Push In Plus firm terminal connection

Even though less insertion force is required, the wires are held firmly in place. With our advanced mechanism design and manufacturing technology, we have produced a spring that allows low insertion f...
